Lunaflex Duct Wrap Insulation (Lagging) – 25mm (18m x 1.2m Roll)

Lunaflex Duct Wrap Insulation (Lagging) – 25mm (18m x 1.2m Roll)

Flexible Thermal & Acoustic Insulation for Ductwork

Our Lunaflex Duct Wrap Insulation provides a practical and effective solution for insulating circular and rectangular duct systems. Designed for HVAC, ventilation, and air movement applications, it helps reduce heat loss, minimise condensation risk, and improve overall system efficiency.

Manufactured from high-performance mineral wool and faced with reinforced aluminium foil, Lunaflex duct wrap offers excellent thermal and acoustic properties while remaining easy to handle and install on site.

Each roll measures 18 metres long x 1.2 metres wide x 25mm thick, making it ideal for both small and large ducting projects.

What is duct wrap insulation used for?

Duct wrap insulation is used to insulate ventilation ductwork in order to:

• Reduce heat loss or heat gain within the system

• Prevent condensation forming on duct surfaces

• Improve acoustic performance by reducing breakout noise

• Maintain system efficiency in both heating and cooling applications

It is commonly used on:

• Spiral duct and rectangular duct systems

• Supply and extract ventilation systems

• Commercial and industrial HVAC installations

• Plant rooms and exposed duct runs

Key Features & Benefits

• 25mm thickness – suitable for general thermal and condensation control

• Large 18m roll – efficient coverage with fewer joints

• 1.2m width – ideal for wrapping larger diameter ductwork

• Thermal insulation – helps maintain system efficiency

• Condensation control – reduces risk of surface moisture

• Acoustic performance – helps reduce noise breakout

• Foil faced finish – durable reinforced aluminium outer layer

• Flexible and easy to install – suitable for circular and rectangular ducts

• Non-combustible material – manufactured from A1 rated mineral wool

Installation Guidance

Lunaflex duct wrap is designed to be wrapped around the external surface of ductwork and secured using:

• Foil tape ( can be found here )

• Banding or insulation pins

• Mechanical fixings where required

All joints and seams should be sealed to maintain vapour control and insulation performance.
